Schneider Electric 140NOE77100 Ethernet network TCP/IP module

Schneider Electric 140NOE77100 Ethernet network TCP/IP module  Specification

Part Number:140NOE77100
Manufacturer:Schneider Electric
Type:I/O Modules
Model:140-NOE-771-00
Warranty:1 Year
Module format：Standard
Product or component type：Ethernet network TCP/IP module
Communication port protocol：Ethernet Modbus TCP/IP
Physical interface：MT/RJ 100BASE-FX fiber optic
Transmission rate：10/100 Mbit/s

Demi Will give you a best price !

Sales Manager:Demi

Email:sales8@askplc.com   Skype: +86 18030235312

Mob|Whatsapp|Wechat :+86 18030235312

About the Schneider Electric 140NOE77100 Ethernet network TCP/IP module

Features of the Schneider Electric 140NOE77100
Peer-to-peer communication is one feature of the Quantum 140NOE77100. It is also manufactured to provide I/O scanning and acts as a Modbus / TCP server. This module is able to include HTTP services. These services aid in maintenance as well as configuration capabilities.

The primary features of the Schneider Electric 140NOE77100 include provisions.  It is enabled with a full-duplex capable twisted shield port with integrated 10/100 BASE-TX. It has a full-duplex capable fiber optic port that is integrated with a 100BASE-FX multimode. The Quantum 140 NOE 771 00 includes an embedded HTTP server as well as a BOOTP client and server. Another feature of the 140 NOE 771 00 is the SNMP V2 agent. It employs flash file system capabilities and has an integrated Modbus I/O scanner.  The Quantum140 NOE 771 00 is capable of using field-upgradeable software over the TCP/IP.  The final highlighted feature of the Quantum 140 NOE 771 00 is the Modbus/TCP client and Modbus/TCP server.

The front panel of the Quantum 140NOE77100 displays many identifying features, including identification markings visible on the front top of the module, complete with color code and LED display. There is a removable hinged door on the front of the Quantum 140 NOE 771 00 module that contains a space for a writable IP (Internet Protocol) address, a global address area, and an area for connector cables. What cables are connected in this space?  This space is provided for two Ethernet connector cables.

Advantages
The Quantum 140NOE77100 modules are equipped with an LED display. This display indicates numerous items relating to the panel.  The LED indicates the operating status of the 140 NOE 771 00 modules as well as both the connected fiber optic and Modbus communications networks.

The front panel allows for recording the preferred written assignments for selected IP addresses. The global address indication is located at the front panel showing the factory-assigned Ethernet MAC address.

The Schneider Electric Quantum 140NOE77100 includes two connections: a 100 BASE-FX Connector and a 10/100 BASE-T Connector. The 100 BASE-FX Connector provides an MT - RJ receptacle.  The MT – RJ receptacle provides a connection to a 100-megabit fiber optic Ethernet cable module. The 10/100BASE-T Connector provides an RJ–45 receptacle. The RJ–45 receptacle is for a shielded, twisted-pair Ethernet cable connection.
